N05 Series 5Nm Non-Fail-Safe Damper Actuator

Name: N05 Series 5Nm Non-Fail-Safe Damper Actuator
SKU: 2007
Price: 999.00 INR
Availability: InStock

Honeywell N05 Series Damper Actuator – 5Nm (44 lb-in), smallest of the N-series, 24 Vac/dc, modulating/floating/2-position.

Product successfully added to the Quote List

Category: Actuators Brand: Honeywell

Description

The Honeywell N05 Series (MN6105/MN7505) Non-Fail-Safe Damper Actuator delivers 5Nm (44 lb-in) torque – the smallest in the non-fail-safe N-series lineup (N05/N10/N20/N34) – for direct-coupled mounting on smaller HVAC dampers. Supply voltage 24 Vac/dc -15%/+20%, 50/60Hz, with modulating, floating, or 2-position control options and a 95°±3° rotation stroke. Universal shaft adapter for single-point mounting, IP54 rated when correctly oriented, weight approximately 1.0 lb (0.45 kg), noise rating 35 dB(A) max at 1m. Jaideo Automation supplies Honeywell building automation products across India – contact us with your project requirements for a quotation.
