Cast Steel Accessible Feed Check Valve -CS-5

Name: Cast Steel Accessible Feed Check Valve -CS-5
SKU: 2182
Price: 999.00 INR
Availability: InStock

Sant CS-5 cast steel accessible feed check valve, OS&Y, 400 degC, IBR certified, DN40-80.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s CS-5 Cast Steel Accessible Feed Check Valve is a right-angle-pattern design with a bolted bonnet, OS&Y (Outside Screw and Yoke) rising stem, renewable seat and disc, in cast carbon steel (ASTM A216 Gr.WCB) with AISI-410 stainless trim, aluminum bronze yoke bush, and expanded pure flexible graphite gland packing. Undrilled flanged ends to BS 10 Table J F.F. Body test pressure 700 psig hydraulic, seat/back seat test 350 psig hydraulic, max working pressure 350 psig (24.61 kg/cm2), rated to 400 degC for water and steam service. IBR Form III-C test certificate furnished with every supply. Available DN40 to DN80 (1.5″ to 3″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
