Bronze Horizontal Lift Check Valve-SBM-11

Name: Bronze Horizontal Lift Check Valve-SBM-11
SKU: 2162
Price: 999.00 INR
Availability: InStock

Sant SBM-11 bronze horizontal lift check valve, Heavy pattern, DN8-100, higher pressure, screwed.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s SBM-11 Bronze Horizontal Lift Check Valve is the Heavy pattern counterpart to SBM-9’s Standard pattern – same leaded tin bronze (IS:318 Gr.LTB2) body/cover/disc, screwed-in cover, integral seat, renewable disc, Cu-alloy trim, screwed female BSP ends to BS 21 – but with a significantly higher pressure rating: body test 35.15 kg/cm2g (500 psig), seat test 21.09 kg/cm2g (300 psig), roughly 50% more than Standard pattern. Works test certificate furnished with every supply. Available DN8 to DN100 (1/4″ to 4″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
