Bronze Right Angle Lift Check Valve-IS-23

Name: Bronze Right Angle Lift Check Valve-IS-23
SKU: 2163
Price: 999.00 INR
Availability: InStock

Sant IS-23 bronze right angle lift check valve, screwed, DN15-100, doubles as elbow fitting.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s IS-23 Bronze Right Angle Lift Check Valve is an angle-type design with a screwed-in cover, in leaded tin bronze (IS:318 Gr.LTB2) with an integral seat, Cu-alloy trim, an NBR O-ring seal, and screwed female BSP parallel ends – the angle pattern lets it double as a 90-degree elbow, saving a fitting where the pipe run changes direction. Body test pressure 300 psig hydraulic, seat test 200 psig hydraulic. Available DN15 to DN100 (1/2″ to 4″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
