Cast Iron Accessible Feed Check Valve – CI-5C

Name: Cast Iron Accessible Feed Check Valve - CI-5C
SKU: 2171
Price: 999.00 INR
Availability: InStock

Sant CI-5A cast iron accessible feed check valve, right-angle, no inspection branch, DN25-65, IBR.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s CI-5A Cast Iron Accessible Feed Check Valve is a right-angle pattern design with straight inlet and no inspection branch, in cast iron (IBR 86 to 93 Gr.A) body/bonnet/disc/gland/handwheel, renewable seat and disc, AISI-410 stainless trim, expanded pure flexible graphite gland packing, aluminium bronze yoke bush, and undrilled flanges to BS 10 Table F or Table H F.F. Body test pressure 21.09 kg/cm2g (Table F) or 26 kg/cm2g (Table H) hydraulic, working pressure up to 13 kg/cm2g at 220 degC steam. IBR Form III-C test certificate furnished with every supply. Available DN25 to DN65 (1″ to 2.5″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
