Bronze Gate Valve-SBM-3

Name: Bronze Gate Valve-SBM-3
SKU: 2068
Price: 999.00 INR
Availability: InStock

Sant SBM-3 Standard-pattern bronze gate valve, PN20, DN15-150, flanged BS 10 Table D ends.

Product successfully added to the Quote List

Categories: Gate Valves, Valves Brand: Sant

Description

Sant’s SBM-3 Bronze Gate Valve is the flanged version of the Standard pattern (vs SBM-2’s screwed ends), built in the same leaded tin bronze (IS:318 Gr.LTB2) body/bonnet/wedge/gland with a forged brass stem (IS:6912 FLB), screwed-in bonnet, non-rising stem, integral seat, and solid wedge. Ends are undrilled flanges to BS 10 Table D F.F. Rated PN-20 (30.60 kg/cm2g body test, 20.40 kg/cm2g seat test). Available DN15 to DN150 (1/2″ to 6″) – a wider size range than the screwed SBM variants, since flanged ends suit larger-bore installations. Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
