Bronze Gate Valve-IS-31

Name: Bronze Gate Valve-IS-31
SKU: 2061
Price: 999.00 INR
Availability: InStock

Sant IS-31 bronze gate valve, IS:778 Class-1, OS&Y rising stem, DN15-100, screwed ends.

Product successfully added to the Quote List

Categories: Gate Valves, Valves Brand: Sant

Description

Sant’s IS-31 Bronze Gate Valve is an OS&Y (Outside Screw and Yoke) type – unlike IS-3’s inside-screw rising stem, the yoke keeps the threaded stem outside the flow path, giving a visible position indicator without exposing the threads to the process fluid. Class-1 to IS-778, leaded tin bronze (IS:318 Gr.LTB2) body/bonnet/wedge, forged brass stem, integral seat, solid wedge, PTFE gland packing, screwed female ends to IS:554. Body test pressure 1.5 MPa, seat test 1.0 MPa hydraulic. Available DN15 to DN100 (1/2″ to 4″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
