Bronze Union Bonnet Horizontal Lift Check Valve – SBM-16

Name: Bronze Union Bonnet Horizontal Lift Check Valve - SBM-16
SKU: 2167
Price: 999.00 INR
Availability: InStock

Sant SBM-16 bronze union bonnet horizontal lift check valve, IS:778 Class 2, PN25, DN15-100, screwed.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s SBM-16 Bronze Union Bonnet Horizontal Lift Check Valve is built to IS:778 Class 2, PN25, with a screwed-on union cover (rather than a screwed-in cover) for easier internal access and servicing without disturbing the pipe connection. Leaded tin bronze (IS:318 Gr.LTB2) body/bonnet/union nut, renewable seat and disc in AISI-410 stainless steel, screwed female BSP parallel ends to BS 21. Body test pressure 42 kg/cm2g (600 psig) hydraulic, seat test 25 kg/cm2g (355 psig) hydraulic – notably higher than the basic IS-14 series. Works test certificate furnished with every supply. Available DN15 to DN100 (1/2″ to 4″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
