Dual Plate Water Check Valve – DP

Name: Dual Plate Water Check Valve - DP
SKU: 2191
Price: 999.00 INR
Availability: InStock

Sant DP dual plate water check valve, wafer type, PN16, DN50-400, spring-loaded.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s DP Dual Plate Water Check Valve is a wafer-type spring-loaded design at PN-16, in cast iron with EPDM rubber seat lining, a ductile iron (SG Iron) disc, hinge pin and stop pin in AISI-420 stainless, spring in AISI-304, and PTFE bush/bearing – the same construction as the DP-1A wafer check but supplied as the base “water check” line for general water service. Wafer type, suitable for clamping between ASME B16.5 Class-150 flanges. Body test pressure 24 kg/cm2, seat test 16 kg/cm2. Available DN50 to DN400 (2″ to 16″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
