Bronze Gate Valve-SBM-1

Name: Bronze Gate Valve-SBM-1
SKU: 2066
Price: 999.00 INR
Availability: InStock

Sant SBM-1 Peglar-type bronze gate valve, PN20, DN8-100, non-rising stem, screwed BS 21 ends.

Product successfully added to the Quote List

Categories: Gate Valves, Valves Brand: Sant

Description

Sant’s SBM-1 Bronze Gate Valve is a Peglar-type, screwed-bonnet design with a non-rising stem, built in leaded tin bronze (IS:318 Gr.LTB2) for body, bonnet, wedge, gland and gland nut, with a forged brass stem (IS:6912 FLB), integral seat, solid wedge, and expanded pure flexible graphite gland packing. Ends are screwed female BSP to BS 21. Rated PN-20 (30.60 kg/cm2g body test, 20.40 kg/cm2g seat test). Available across a wide size range, DN8 to DN100 (1/4″ to 4″), covering smaller sizes than Sant’s standard SBM-2/SBM-3 range. Suited to water and oil piping needing a compact non-rising-stem shutoff valve. Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
