Bronze Horizontal Lift Check Valve-IS-15A

Name: Bronze Horizontal Lift Check Valve-IS-15A
SKU: 2160
Price: 999.00 INR
Availability: InStock

Sant IS-15A bronze horizontal lift check valve, IS:778 Class-2, ISI marked, DN15-100, flanged, higher pressure.

Product successfully added to the Quote List

Categories: Check Valve, Valves Brand: Sant

Description

Sant’s IS-15A Bronze Horizontal Lift Check Valve is the Class-2 counterpart to IS-15 – same leaded tin bronze (IS:318 Gr.LTB2) body/bonnet/disc, screwed-in cover, integral seat, Cu-alloy trim, and undrilled flanges to IS:778 (Class-2 F.F.) – with a higher pressure rating: body test 2.4 MPa, seat test 1.6 MPa hydraulic (vs 1.5/1.0 MPa for IS-15 Class-1). ISI marked, max working temperature 45 degC. Available DN15 to DN100 (1/2″ to 4″). Jaideo Automation supplies Sant valves across India – contact us with your size for a quotation.
