Check Valve Flanged Type

Name: Check Valve Flanged Type
SKU: 1604
Price: 999.00 INR
Availability: InStock

Kartar Check Valve, Flanged Type (K-104) – lift-check, right-angle body, full flanged DIN-2533 PN-16 ends, steam-rated to 13 Kg/cm2.

Product successfully added to the Quote List

Categories: Check Valve, Plumbing Brand: Kartar

Description

The Kartar Check Valve, Flanged Type (K-104 Cast Iron Lift Check, Right Angle) uses a lift-check mechanism with a right-angle body pattern and full flanged end connections to DIN-2533 RF (PN-16) – a genuinely different design from the Single Plate and Dual Plate NRVs, which use wafer end connections (fitting between pipe flanges) with a swing-check mechanism. Bolted cover with renewable Stainless Steel (AISI-410) seats. Body tested to 370 PSIG (26 Kg/cm2) hydraulic, seat and back seat tested to 230 PSIG (16 Kg/cm2). Suitable for steam up to 13 Kg/cm2, max working temperature 220°C – a steam-rated capability the wafer-style Single/Dual Plate valves don’t carry. Jaideo Automation supplies Kartar valves across India – contact us with your project requirements for a quotation.

Brand

Kartar

Kartar Valves & Firefighting Products

Kartar is an Indian manufacturer of valves, pipe fittings and firefighting products, with a product range covering ball valves, butterfly valves, check valves, gate valves, strainers, air valves and other flow-control solutions. Jaideo Automation supplies Kartar products for HVAC, plumbing, water management, fire protection and industrial applications across India.
